Gear Geometry & Construction
P1 — Small Gears (11–15T / 11–16T)
Split-piece CNC-machined gears.
P2 — Mid Gears (17–27T)
Monoblock CNC construction using special titanium alloy to maximize stiffness and torque resistance.
P3 — Large Gears (30T / 34T / 35T)
7075-T6 aerospace aluminum sprockets reduce rotational mass while maintaining structural integrity.
